(HOME) Station AJ8MH - Marquette, Michigan

The cabin "Radio Room" near Gwinn in Michigan's Upper Peninsula

Heigh-ho, heigh-ho...it's off to camp we go!




  In July of 2006, I operated HF from Michigan for the first time in 45 years.  I was 11 years old and held the call WN8AQL the last time I had a QSO from the Marquette county area.  I have now returned to Michigan's Upper Peninsula and spend part of the year operating from our cabin on Pike Lake.

The cabin is located 20 miles south-southwest of Marquette, MI (and Lake Superior) near Gwinn, and a half mile from one leg of an abandon Extremely Low Frequency communications antenna line that was associated with Project ELF.*

When operating from our cabin in the woods, I use a Yaesu FT-847 that I originally purchased in early 1999.  The antenna is a modified ZS6BKW configured as an inverted-V doublet at 35 feet (broadside E/W).  I added a 30 meter wire element for better tuning on that band.  The antenna is fed with ladder-line through a remote 1:1 choke. The tuner is an auto MFJ-993B.

  I also use a 26 foot short horizontal doublet fed with ladder line through a second 1:1 choke.  It's broadside NE/SW.  I use a homebrew aluminum dipole up about 15 feet for 6 meters.  It's broadside E/W.  I'm still looking for Alaska and Hawaii to finish Worked All States on 6.

I use a laptop and an iPhone as a personal hotspot for Internet service, so the computer isn't used very much except when connected to the radio for digital modes.

Joe (AJ8MH)
ex: WPE8EUM, WN8AQL, WB5FCO and WJ5MH

*See old Project ELF notes and photographs below.

Cabin in the Woods



Fishing is Good...  That's a modified tennis-racket in picture!  Pike Lake holds Crappie, Pumpkinseed - Sunfish, Bluegill, Perch, Smallmouth/Largemouth Bass (min 14" limit), Northern Pike (min 24" limit) and Walleye (min 15" limit).

Old Project ELF Submarine Communications System

  Project ELF became operational in 1989 and was designed to communicate with deeply-submerged submarines.  It consisted of two transmitter sites, one near Clam Lake in Northern Wisconsin, and the other near Republic. The sites were separated by 145 miles.  (The main transmitter in Michigan was 7 miles southeast of Republic at 3041 County Road FFG.)

In Michigan, three antenna lines were used in an area south of Republic, north of Iron Mountain and West of Gwinn.  Two lines were about 14 miles long and one was roughly 28 miles long.  These lines were laid out loosely resembling the letter "F" with the longest line running north-south, and the smaller lines running east-west.

Some research needs to be done to verify this, because the line by camp appears to run north-northeast, north and then north-northwest from its termination point.

(Update 2011:  Once I located the transmitter site using satellite images, I was able to trace the antenna lines, and it's clear that the lines seldom ran in a straight line.  They also seemed to have termination "fingers" at the end of each run.  On September 1st, I took my wife and our little dog on a drive to the site.  The gate across the main road was locked, but no "no trespassing" signs were posted, so we walked to the main compound area and took pictures of the abandon site.  I believe the site is still for sale.)

(Update 11/14/2011:  In an article by the Associated Press, the Defense Department was offering $400,000 to demolish the installation, so the Humboldt Township community decided to look for ways to reuse the 6.9 acre site and keep the money in the county's coffers.  The township should get title to the property early in 2012 pending completion of the second round of environmental clearances.)

(Update 08/04/2012:  On August 1, 2012 the site was turned over to Humboldt Township. The township is still deciding how best to use the site. Options include a community center or disaster relief site.)

  (Update 10/12/2022:  According to an article in the Alpina News written by Jeffrey D. Brasie of suburban Detroit, Humboldt Supervisor Thomas Prophet stated the township has subsequently sold the property for $230,000 to a private developer.  He added, "Most of the buildings, fencing, and security system remain intact, and the property is now used for growing marijuana.")

The antenna line looked like a single power-line mounted on 40-foot wooden poles.  It's been reported that the typical operating frequency was centered around 76 Hz.

The project was closed down in 2004, but some hardware remains.  Mostly just the poles are standing today.  (Update 2008:  Poles have been removed, and I haven't found any other evidence of the antenna system.)

You can find additional information on Project ELF throughout the WEB, but a lot of it from anti-nuclear weapons activists involved in a long campaign against what they dubbed a "nuclear war trigger."  John LaForge of Nukewatch helped coordinate the Coalition to Stop Project ELF.*

Bonnie Urfer, co-director of Nukewatch said, "I feel relief for the people of the area and the local environment, knowing that ELF's million-point-three watts of electricity will no longer be jolted into the ground, shocking the aquatic life and increasing the threat of leukemia and other cancers."*

So far, the fish I've caught seem to be healthy and not abnormally large or disfigured, and I haven't seen any strange creatures roaming the backwoods, although Bigfoot (Sasquatch) has been reported in the area.  (My outhouse is unlocked in case he stops by some evening.)  Also, reports of an underground alien spaceport located in the Upper Peninsula have been greatly exaggerated.

*Information from The Nuclear Resister, Nr. 135, PROJECT ELF CLOSES dated October, 2004.
